HARDWARE FEATURES

Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

Interface 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

100BASE-TX: UTP category 5, 5e or above cable (maximum 100m)

Fan Quantity Fanless

Power Supply External Power Adapter(Output: 9VDC/0.6A)

Power Consumption Maximum: 3.19W (220V/50Hz)

Dimensions ( W x D x H ) 11.6*7.1*1.7 in. (294*180*44 mm)

Mounting Rack Mountable

Max Power Consumption 3.19W(220V/50Hz)

Max Heat Dissipation 10.88BTU/h

PERFORMANCE

Switching Capacity 4.8Gbps

Packet Forwarding Rate 3.57Mpps

MAC Address Table 8K

Buffer Memory 2Mb

Green Technology Innovative energy-efficient technology saves power up to 75%

Transfer Method Store-and-Forward

OTHERS

Certification FCC, CE, RoHS

Package Contents 24-Port 10/100Mbps Desktop/Rackmount Switch

Power Cord

Installation Guide

Rackmount Kit

Rubber Feet

Environment Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

TP-Link 24 Port TL-SF1024D 100Mbps Switch Hub

Rp 640.000
