ESP32-C3-DevKitM-1 is an entry-level development board that uses small-sized ESP32-C3-MINI-1 modules. This development board has complete Wi-Fi and low power Bluetooth capabilities

ESP32-C3-MINI-1 is a universal Wi-Fi and low power Bluetooth dual-mode module with PCB on-board antenna. This module integrates a 4 MB embedded flash ESP32-C3FN4 chip.

CPU and on-chip memory:

Built-in ESP32-C3FN4 chip RISC-V 32-bit single-core microprocessor with a dominant frequency of up to 160 MHz

384 KB ROM

400KB SRAM (of which 16KB is dedicated to cache)

8 KB RTC SRAM

4MB embedded flash

WiFi:

Support IEEE 802.11 B/g/n protocol

Center frequency range of working channel: 2412~2484 MHz

Supports 20 MHz and 40 MHz bandwidths in the 2.4 GHz band

Supports 1T1R mode with data rate up to 150 Mbps

Wireless Multimedia (WMM)

TX/RX A- MPDU, TX/RX A- MSDU

Immediate Block ACK

Fragmentation and defragmentation

Transmission opportunity, TXOP

Beacon Automatic Monitoring (Hardware TSF)

4 × Virtual Wi-Fi Interface

At the same time support Infrastructure BSS

Station mode, SoftAP mode, Station SoftAP mode and promiscuous mode Please note that when the ESP32-C3 series is scanned in Station mode, the SoftAP channel will change at the same time.

802.11 mc FTM

Bluetooth:

Advertising Extensions

Multiple Advertisement Sets

Channel Selection Algorithm #2

Wi-Fi and Bluetooth coexist and share the same antenna.

Peripheral:

GPIO, SPI, UART, I2C, I2S, remotecontrol peripheral, LED PWM controller, universal DMA controller

esp32-C3 Mini devkitM wifi bluetooth development board module

esp32-C3 Mini devkitM wifi bluetooth development board module
