Fitur Mikrokontroler:

- STM32F446RET6 in LQFP64 package

- ARM32-bit Cortex-M4 CPU with FPU

- Adaptive real-time accelerator (ART Accelerator) allowing 0-wait state execution from -

Flash memory

- 180 MHz max CPU frequency

- VDD from 1.7 V to 3.6 V

- 512 KB Flash

- 128 KB SRAM System

- 4 KB SRAM Backup

- Timers General Purpose (10)

- Timers Advanced-Control (2)

- Timers Basic (2)

- SPI (4)

- I2S (2)

- USART (4)

- UART (2)

- USB OTG Full Speed and High Speed

- CAN (2)

- SAI (2)

- SPDIF-Rx (1)

- HDMI-CEC (1)

- Quad SPI (1)

- Camera Interface

- GPIO (50) with external interrupt capability

- 12-bit ADC (3) with 16 channels

- 12-bit DAC with 2 channels

Fitur Board Nucleo:

- Two types of extension resources

- Arduino Uno Revision 3 connectivity

- STMicroelectronics Morpho extension pin headers for full access to all STM32 I/Os

- On-board ST-LINK/V2-1 debugger/programmer with SWD connector

- Selection-mode switch to use the kit as a standalone ST-LINK/V2-1

- Flexible board power supply

- USB VBUS or external source (3.3 V, 5 V, 7 - 12 V)

- Power management access point

- User LED (LD2)

- Two push buttons: USER and RESET

- USB re-enumeration capability: three different interfaces supported on USB

- Virtual Com port

- Mass storage (USB Disk drive) for drag'n'drop programming

- Debug port

NUCLEOF446RE

Rp 685.000
