ESP32 ESP-32 ESP-WROOM-32 ESP32S ESP-32S ESP-WROOM-32S Modul Module Mix Antenna

Ini adalah Modul Mikrokontroler ESP32 Wroom-32S. Modul ini cocok untuk berbagai macam proyek Artificial Intelligence (AI) dan juga proyek Internet of Things (IoT).

FITUR LENGKAP DARI ESP32 Wroom-32S:

- WiFi Protocols : 802.11 b/g/n/d/e/i/k/r (802.11n up to 150Mbps)

- Frequency Range : 2.4GHz-2.5GHz (2400M-2483.5M)

- Bluetooth Protocols : Bluetooth v4.2 BR/EDR and BLE specification

- Radio : Class-1, class-2 and class-3 transmitter

: AFH

- Audio : CVSD and SBC

- Module interface : SD card, UART, SPI, SDIO, I2C, LED PWM, Motor PWM, I2S, I2C, IR

: GPIO, capacitive touch sensor, ADC, DAC, LNApre-amplier

- On-chip sensor : 3.0~3.6V

- On-board clock : Average value: 80mA

- Operating voltage : -40°~125° Operating current Normal temperature

- Operating temperature range : 14.3mm*24.8mm*3mm

- Ambient temperature range : N/A

- Wi-Fi mode : Station/softAP/SoftAP+station/P2P

- Security : WPA/WPA2/WPA2-Enterprise/WPS

- Encryption : AES/RSA/ECC/SHA

- Firmware Upgrade : UART Download / OTA (via network) / downloadand write firmware via host

- Software Development : Supports Cloud Server Development / SDKfor custom firmware development

- Network Protocols : IPv4, IPv6, SSL, TCP/UDP/HTTP/FTP/MQTT

- User Configuration : AT instruction set, cloud server, Android/iOSApp

- Atenna : Mix Antenna (On Board Antenna dan External Antenna tipe IPX / U.FL)

Datasheet: https://www.es.co.th/Schemetic/PDF/ESP32.PDF

ISI PAKET:

- 1 buah Module ESP32 Wroom-32S

#microcontroller #mikrokontroler #Modul #Module #ESP #Wroom-32S #ESP32S #DOIT #IoT

ESP-32S ESP-WROOM-32 ESP32S Blue tooth and WIFI Dual Core CPU Module

ESP-32S ESP-WROOM-32 ESP32S Blue tooth and WIFI Dual Core CPU Module

Rp 68.796
