INTRODUCTION

What's the difference between Raspberry Pi and Arduino?

We all know Raspberry Pi is a mini-computer running on Linux operating system; while Arduino is a microcontroller running on simple I/Os. Both of them focuses on very different areas. Compared with Arduino, the Pi gets much better computing performance.

So What happens when a Raspberry Pi meets an Arduino?

A simple example would be, when building a mobile robot, we use the Raspberry Pi to extend its vision and get a nice tiny monitor. Meanwhile, Arduino handle nicely with the motor driving part and delivers fast responses like obstacle avoidance. Because, without the OS, the response time of rapid changes on the Arduino is much shorter. Also the high performance Pi can deals much easily with wireless communications, imaging and running complex algorithm..

FEATURES

Integrate with the Xbee socket

Easy connection with Arduino and Raspberry Pi directly

Compatible with BLE Link(BT4.0)/Bluetooth Bee(BT2.1) and Xbee modules

Embeded DS1307 RTC module, which keeps time of the Pi even when the power is off, or when battery removed

Bidirectional logic converter for Raspberry Pi GPIO to convert signal between 3.3v and 5v

3 pin headers sensor port for Arduino pins and Pi GPIO, directly compatible with hundreds of Arduino sensors and modules

Arduino shield compatible layout makes it possible to extend Arduino shield features for your Pi

SPECIFICATION

Onboard Microcontroller: ATmega32u4

Arduino Leonardo Chip

Arduino Compatible pin mapping

Compatible with All arduino standard shield and sensors

System Voltage: 5v

Extended 8 Raspberry Pi GPIO with Stardard 3pin sensor pin headers

Extended Raspberry Pi SPI & I2C and UART port

Dimension: 88mm x 56mm x 17mm(3.46"x2.20"0.67")

OPTIONAL PARTS

Relay Module V3.1 for IOT AC control

Analog pH Meter Kit for monitoring Water quality of your pool

SHIPPING LIST

Arduino Expansion Shield for Raspberry Pi B+ x1

20cm micro USB cable x1 CR1220 battrey not include flight constrain

Arduino Expansion Shield for Raspberry Pi model B

Arduino Expansion Shield for Raspberry Pi model B
