Weather is one of the most important factors for human and life and food security, and wind speed is one of the elements to measure in weather stations.

This is a wind speed detector or a.k.a anemometer. It is portable, easy to carry and assembly, made of polycarbon which is anti-corrosion rust at the same time to overcome the ABS plastic aging problems. The bottom outlet and the outlet side of the equipment are compatible with each other.

Interface/Output: RS485 communication (modbus) protocol

Baud rate: 2400, 4800 (default), 9600

Data bit length: 8 bits

Parity check method: None

Alternative Interface/Output: 5-420MA

Application:

Measurement of Horizontal Wind Velocity at Near-Surface Layer of Port

Meteorological environment

Airport Expressway Monitoring

Agriculture and forestry, environmental protection industry

This is an example schematic diagram for the connection between NPN Anemometer and Arduino. This connection requires a pull-up resistor to logic voltage, recommended to use a 5.1k Ohm resistor.

Features

Specifications:

Wind Speed sensor or Anemometer

Material: Poly-carbon

Weight: Approx. 336g / 11.9oz

Package Size: Approx. 19x17.5x17cm / 7.5x6.9x6.7in

Power supply (default): 10~30V DC, we have tested this sensor with 5V from Arduino and it works fine.

Operating temperature -20℃~+60℃

Operating Humidity: 0% RH~80% RH

Wind Speed range: 0 to 70m/s

Minimum detectable wind speed: 0.2m/s

Interface/Output: RS485 or Open Drain output, 100mA maximum current sink

Wiring:

Brown: VCC (positive) power, 5V to 30VDC

Black: GND, 0V

Blue: Output, require pull up resistor to logic voltage, recommended 5.1K Ohm

Green: NC (Not Connected)

Pulses Per Rotation: 20 pulses per rotation

Wind speed: 1.75m/s = 20 pulses per second

The below shows the size image for 5V Wind Speed Anemometer RS485 Output:

Pilih varian interface yang di perlukan ( Output 0-5V / RS485 / 4-20MA).

NO RETURN / NO KOMPLAIN
