Ready Stock

Module untuk mendeteksi kualitas udara.

Feature Applications

* Long life

* Air purifier

* High sensitivity

* Air quality monitoring

* Automatic calibration

* Air ventilation system

* Comes with temperature & humidity compensation

* Low cost

Specification:

* Module model: AQM-300C

* Sensor: AQS501 air quality monitoring sensor

* Gas detection : ammonia, hydrogen, alcohol, carbon monoxide, methane, propane, Gan alkyl, styrene, propylene glycol, phenol, toluene, ethylbenzene, xylene, formaldehyde and other volatile organic gas, such as cigarettes, wood , paper burning smoke.

* Physical interface: XH2.54-4 vertical outlet

* Output data: TTL levelbuilt-in 200ohm current limiting resistance)

* Input voltage: 5.00.2VDC (without voltage reverse polarity protection)

* Operating current: 80mA

* Warm-up time: 2 minutes

* Response time: 10 seconds

* Recovery time: 20 seconds

* Operating temperature: -10 --- 40

* Operating humidity: 95RH

* Storage temperature: -20 --- 60

* Storage humidity: 60RH

* Dimension: 242015LWH)

* Weight : About 20g

* Sensitivity : 1ppm hydrogen

* Sensitivity reduction : 0.2%/year

* Life: 10 years

Interface definition:

1. Power supply negative

2. Power supply positive +

3. Output signal A

4. Output signal B

Air quality module

Air quality module

Rp 294.000
