Product Description

*High Precision

*Capacitive Type

*Outstanding Long-Term Stability

*Full Range Temperature Compensated

*Relative Humidity And Temperature Measurement

*Calibrated Digital Signal

*Extra Components Not Needed

*Long Transmission Distance, Up To 100 Meters

*Low Power Consumption

*Three-Core Shielded Cable As Outgoing Line

Description:

SE-RHT05 Output Calibrated Digital Signal. It Applys Exclusive Digital-Signal-Collecting-Technique And Humidity Sensing Technology, Assuring Its Reliability And Stability. Its Sensing Elements Is Connected With 8-Bit Single-Chip Computer.

Every Sensor Of This Model Is Temperature Compensated And Calibrated In Accurate Calibration Chamber And The Calibration-Coefficient Is Saved In Type Of Programme In OTP Memory, When The Sensor Is Detecting, It Will Cite Coefficient From Memory.

Small Size & Low Consumption & Long Transmission Distance(100m) Enable SE-RHT05 To Be Suited In All Kinds Of Harsh Application Occasions. Single-Row Packaged With Four Pins, Making The Connection Very Convenient.

Technical Specification:

*Model SE-RHT05

*Power Supply 3.3-6V DC

*Output Signal Digital Signal Via 1-Wire Bus

*Sensing Element For RH Polymer Humidity Resistor

*Sensing Element For T Apply Dallas DS18B20 For Detecting Temperature

*Operating Range Humidity 0-100%RH; Temperature -40~120Celsius

*Accuracy Humidity +-2%RH(Max +-5%RH); Temperature +-0.3Celsius

*Resolution Or Sensitivity Humidity 0.1%RH; Temperature 0.1Celsius

*Repeatability Humidity +-1%RH; Temperature +-0.2Celsius

*Humidity Hysteresis +-0.3%RH

*Long-Term Stability +-0.5%RH/Year

*Interchangeability Fully Interchangeable

AM2305 Digital Temperature and Humidity Sensor

AM2305 Digital Temperature and Humidity Sensor

Rp 349.000
