TL-SG105 Metal Case

5-Port 10/100/1000Mbps Desktop Switch

5 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX

Green Ethernet technology saves power consumption

IEEE 802.3x flow control provides reliable data transfer

Steel housing, desktop or wall-mounting design

Support 802.1p/DSCP QoS and IGMP Snooping function

Plug and play, no configuration needed

HARDWARE FEATURES

- Standards and Protocols : IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p

- Interface : 5 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports

- Fan Quantity : Fanless

- External Power Supply : External Power Adapter (Output: 5VDC / 0.6A)

- LED Indicator : System Power Link/Act indicators per port built into each RJ-45 port

- Dimensions ( W x D x H ) : 3.9 x 3.9 x 1.0 in. (100 x 98 x 25 mm)

- Max Power Consumption : 2.3W (220V/50Hz)

- Max Heat Dissipation : 7.83 BTU/h

PERFORMANCE

- Packet Forwarding Rate : 7.4Mpps

- MAC Address Table : 2K

- Packet Buffer Memory : 1Mb

- Jumbo Frame : 16KB

SOFTWARE FEATURES

Advanced Features :

- Green Technology

- 802.3X Flow Control

- 802.1P/DSCP QoS (for V2 and later version)

- IGMP Snooping

- Transfer Method : Store and Forward

OTHERS

- Certification : CE, FCC, RoHS

Package Contents :

1 x 5-Port 10/100/1000Mbps Desktop Switch

1 x 5V-0.6A Power Adapter

1 x Installation Guide

Environment :

- Operating Temperature : 0°C~40°C (32°F~104°F)

- Storage Temperature : -40°C~70°C (-40°F~158°F)

- Operating Humidity : 10% ~ 90% non-condensing

- Storage Humidity : 5%~90% non-condensing

TP-LINK TL-SG105 5-Port Gigabit Desktop Switch Hub - TPLINK SG-105

Rp 245.000
