Processor Qualcomm Atheros 560MHz CPU, MIPS 74Kc

Memory 64MB DDR2 RAM, 8MB Flash

Interface

1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in)

1 10/100Mbps Shielded Ethernet Port (LAN1)

1 Grounding Terminal

1 Reset Button

Enclosure Outdoor ASA stabilized plastic material

IPX5 waterproof Certification

WIRELESS FEATURES

Wireless Standards IEEE 802.11b/g/n (with Pharos MAXtream disabled)

Proprietary Protocol TDMA Mode (with Pharos MAXtream enabled)

Frequency 2.4~2.483GHz

Note: Available operating frequency may vary depending on the limitations

of the countries or regions in which the device is used.

Transmission Power 30dBm/1000mw (Adjustable power by 1dBm)

Note: Maximum transmission power may vary across different channels depending

on the limitations of the countries or regions in which the device is used.

SOFTWARE FEATURES

Wireless Configurations:

Pharos MAXtream TDMA Technology

802.11b/g/n Modes

Selectable Channel Width: 5/10/20/40MHz

Automatic Channel Selection

Transmission Power Control

Dynamic Frequency Selection (DFS)

WDS Enable/Disable

Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption

SSID Broadcast Enable/Disable

Multi-SSID with VLAN Tagging (AP mode only)

Distance/ACK Timeout Setting

Wireless MAC Address Filter

Wireless Advanced:

> Beacon Interval/RTS Threshold/Fragmentation

>Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia

Management:

Discovery and Remote Management via Pharos Control application

HTTP/HTTPS Web-based management

System Log

SNMP Agent(v2c)

Ping Watch Dog

Dynamic DDNS

SSH Server

System Requirements:

Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 10, Windows 8, Windows 7,

MAC OS, NetWare, UNIX or Linux.

Package Contents:

Outdoor Wireless CPE

24V 0.5A Passive PoE Adapter

Pole Mounting Straps

AC Power Cord

Installation Guide

TP-LINK CPE220 2.4GHz 300Mbps 12dBi Outdoor CPE - TPLINK CPE 220

TP-LINK CPE220 2.4GHz 300Mbps 12dBi Outdoor CPE - TPLINK CPE 220

Rp 550.000
