MW300RE

300Mbps Wi-Fi Range Extender

Range Extender mode boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly

Three external antennas with MIMO technology help set the MW300RE apart from ordinary range extenders

Easily expand wireless coverage at easy two-touch setup or a push of WPS button

Miniature size and wall-mounted design make it easy to deploy and move flexibly

The multicolor LED helps you to find the right location to deliver the best Wi-Fi extension

WirelessWireless Standards

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency

2.4 - 2.5GHz

WiFi Speeds Up to 300Mbps Reception Sensitivity

• 11g54M: -79dBm

• HT20MCS7: -76dBm

• HT40MCS7: -72dBm

Transmission Power <20dBm Wireless Security

WPA-PSK/WPA2-PSK

HardwareDimensions

101 x 74.8 x 75.8 mm

Button Reset/WPS Button Antenna Type

3 external antennas

OthersCertifications CE, ROHS Package Contents

300Mbps Wi-Fi Range Extender MW300RE

Quick Installation Guide Environment

Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)

Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

MERCUSYS MW300RE 300Mbps Range Extender Penguat Signal WiFi - MW-300RE

Rp 168.000
