Description:

Brand: ToolkitRC

Item: ST8 Servo Tester

Channel: 8CH Output

Load(max): 100W

Input Voltage: 7.0-28.0V@MAX 10A

Main Output Voltage: 5.0-28.0V@MAX 10A

Signal Output Voltage:

5.0-8.4V@MAX 2A(S1-S4)

5.8-8.4V@MAX 4A(S1-S4)

Output Signal:

100us-2900us@33-1000Hz @S1-S4

PWM 500us-2500us @S5

PPM 8CH @S5

SBUS 16CH @S5

P1 Button: 1000-2000us @P1

Micro USB: Update@USB3.0

Display: 2.4" TFT RGB LCD Screen(320*240 resolution)

Product Size: 96*68*26mm Approx.

Packing Size: 105*80*45mm Approx.

Net Weight(Approx): 140g

Gross Weight(Approx): 160g

Using Steps:

① Connect 7-28V power supply,After power-on, the LCD screen displays the logo and continues 2 seconds, with the starting music;

② Press "EXIT" button to test PWM signal;

③ Totate the Button to choose different channel and press "EXIT" to confirm;

④ Long-press the "OK" button(2s) to entra system setting;

⑤ Press "EXIT" to finish setting;

Features:

- ToolkitRC ST8 is a data analyzer which is capable to test the voltage, power, current, speed and signal data of the servo.

- With 4-way independent programable signal, 8 channel signal output, the precision is accurating to 1us.

- 4-way independent current date collection, and diplayed by graph.

- Support to test multipul date, speed, liner data, steps,etc.

- Support multiple signal type, PWM/PPM/SBUS,the precision is accurating to 1us.

- Input Voltage is higher to 28V, also suitable to test HV servo.

- The max load is upto 100W.

- Multi-language system, can change the language by yourself.

- USB firmware update, easy to operate.

Note:

- S1-S4, S4 EXT signal interface support MAX 2A current, please connect to main interface when the current of servo is higher than 2A.

- S1-S4 signal interface support MAX 8.4 voltage, please connect to main interface when the voltage of servo is higher than 2A.

Package:

1* ToolkitRC ST8 Servo Tester

1* USB Wire

1* Manual

ToolkitRC ST8 8CH 100W 2A 7-28V LCD Servo Special Tester

Rp 892.000
