Specification

Wheelbase: 319MM (Maximum Adjustable 343MM Minimum 295MM)

Size

Front width: 74MM / 2.91 "

Rear: 118MM / 4.65 "

Shaft: 171MM / 6.73 "(Excluding the Hex)

Total Length: 519MM / 20.43 "

Weight: 2.7KG

Material: Metal

Scale: 1/10

Function: Off-road

Drive: Electronic Drive (Fit 540 motor recommend 21T)

Requires Assembly

Features

FRAME REL CHASSIS:

• Ultra scale looks and superior quality and craftsmanship

• Made of durable steel

C channel structure and cross braces increase chassis rigidity (torsional stiffness)

More additional holes have been added to the frame rails to make the wheelbase (adjustment (Maximum 343MM, minimum 295MM)

TRANSMISSION:

• Front Mounted Moter (NOTE: motor is not included.)

• Realistically detailed transmission housing in a cast metal look

• All metal internal Teeth

• 3 output shafts, Forward / Backward, linear + inertial output

• Realistic cooling fan scale (Equipped with mini motor and belt drive)

• Adjustable installation

• Gear ratio 1: 24.8

US:

• Die cast zinc alloy housing

• Ackermann steering, up to 45 degrees

• Front / Rear panhard bar

• Reverse transmission, smooth action for efficient drivetrain

• Hardened steel helical gear set

• Compact but durable design

• Gear ratio 1: 3 6

SHOCK:

• Separate design, Spring + shock damping

• Compact but durable design

• Highly detailed and super realistic organ cover style

DRIVE SHAFT:

• Front and rear drive shafts feature a new design for added strength

• Added carbon hardened steel material which reduces flex and fatigue

• Hexagon splined slideroffers for super long travel and super smooth operation

SUSPENSION

The link rod is made of heat treated carbon steel to withstand extreme conditions and the black rubber boot protects the link rod from the elements for even durability when adding to scale.

Required to Complete:

Wheels, Tire, Body, Motor (Recommend 540 21T motor), ESC, RXTX (min 3ch), Servo, Lipo+Charge

RCRUN RUN80 1:10 Scale LC80 Metal Chassis Builder Kit

RCRUN RUN80 1:10 Scale LC80 Metal Chassis Builder Kit

Rp 6.597.000
